High-Efficiency Activated Carbon Air Filter for Industrial Odor & Gas Removal
Our Activated Carbon Air Filters are the premier choice for industrial odor removal and advanced gas filtration. Specifically engineered to neutralize acidic and alkaline gases , these filters help facilities maintain superior indoor air quality and meet strict environmental emission standards. By combining physical dust capture with chemical adsorption, this dual-action carbon filter provides a comprehensive solution for complex air quality challenges.
Product Key Features
Advanced Odor Removal & Filtration: Features a dual-function design that simultaneously adsorbs chemical odors and filters airborne particulates.
High Efficiency Adsorption: Certified to achieve an adsorption efficiency of ≥80%, meeting professional G3 and G4 filtration class standards.
Low Resistance Airflow: Our low resistance carbon air filters maintain an initial pressure of only 35Pa , ensuring high energy efficiency even in high air volume applications.
Acid and Alkaline Gas Filtration: Specifically formulated activated carbon cotton media provides high-capacity capture of corrosive and odorous chemical gases.
Customizable Structural Designs: Available in pleated, parent-child frame, bag, and flat panel configurations to fit any HVAC activated carbon filter slot.
Material & Craftsmanship
Durable Industrial Frames: Built with professional aluminum profiles or heavy-duty galvanized iron to ensure structural integrity.
Premium Filter Media: Utilizes activated carbon powder-impregnated cotton in thicknesses of 3mm, 5mm, or 10mm for maximum chemical capture.
Reinforced Support: Protected by painted square mesh or aluminum mesh to prevent media deformation under pressure.
Applications
Central HVAC Systems: The ideal activated carbon filter for central air conditioning systems to remove tobacco smoke, office odors, and circulating VOCs.
Cleanrooms & Labs: Provides critical protection in pharmaceutical or semiconductor environments by capturing trace chemical contaminants.
Industrial Exhaust Treatment: An essential industrial exhaust air filter for environmental standards, neutralizing waste gases before discharge.
Chemical & Food Processing: Effectively mitigates strong smells in facilities dealing with chemical reagents or large-scale food preparation.
Competitive Comparison
| Feature | Chuqi High-Performance Carbon Filters | Standard Primary Filters | The Chuqi Advantage |
| Gas & Odor Control | Dual-action: Captures particles and neutralizes acidic/alkaline/VOC gases. | Purely physical: Only captures dust; fails to remove odors. | Cleaner Environment: Specifically engineered for total air purification, not just dust control. |
| Adsorption Efficiency | High Density: Certified ≥ 80% adsorption efficiency (G3/G4 level). | Often unrated for gas; negligible chemical adsorption capacity. | Superior Purity: Effectively removes industrial exhaust and kitchen odors to meet environmental standards. |
| Structural Stability | Precision Build: Optional double-layer galvanized steel skeletons for “Parent-Child” frames. | Weak Support: Prone to media collapse or bypass under high airflow. | Zero Bypass: Ensures 100% filtration integrity and prevents media deformation during operation. |
| Airflow Management | Optimized Resistance: Maintains a low initial resistance of approximately 35Pa. | High Resistance: Restricts airflow, leading to higher HVAC energy consumption. | Energy Efficiency: Provides massive airflow (up to 40003/h) with minimal system strain. |
| Design Versatility | Multi-Configuration: Available in Pleated, Bag, Panel, and Skeleton types. | Limited Selection: Usually restricted to standard flat panel profiles. | Flexible Fit: Easily adapts to various industrial HVAC housings and space-restricted slots. |
| Frame Durability | Industrial Grade: Choice of Aluminum Profile or heavy-duty Galvanized Iron frames. | Fragile Build: Often uses low-grade plastic or cardboard frames. | Rugged Build: Provides the long-term structural integrity required for precise industrial air control. |
Specifications
| Dimensions (mm) | Rated Airflow (m3/h) | Initial Resistance (Pa) | Adsorption Efficiency | Filtration Class | Filter Media Type |
| 295 × 295 × 46 | 10003/h | 35 Pa | ≥80% | G3 / G4 | Black cotton with activated carbon powder |
| 495 × 295 × 46 | 16003/h | 35 Pa | ≥80% | G3 / G4 | Black cotton with activated carbon powder |
| 495 × 495 × 46 | 28003/h | 35 Pa | ≥ 80% | G3 / G4 | Black cotton with activated carbon powder |
| 595 × 295 × 46 | 20003/h | 35 Pa | ≥ 80% | G3 / G4 | Black cotton with activated carbon powder |
| 595 × 495 × 46 | 33003/h | 35 Pa | ≥80% | G3 / G4 | Black cotton with activated carbon powder |
| 595 × 595 × 46 | 40003/h | 35 Pa | ≥ 80% | G3 / G4 | Black cotton with activated carbon powder |
As a specialized manufacturer with 20 years of production experience in the air filtration industry, Chuqi New Materials is dedicated to delivering high-performance solutions that exceed international B2B expectations. Our expertise in industrial odor removal is built into every activated carbon air filter we produce, featuring a certified adsorption efficiency of $\ge$ 80% specifically engineered for acidic and alkaline gas filtration. We take pride in our “Rugged Build” philosophy, utilizing premium aluminum profiles and galvanized iron frames to ensure that our low resistance carbon filters maintain structural integrity even in the most demanding high-airflow environments.
Frequently Asked Questions
Q:What are the primary applications for this filter?
It is mainly used to filter acidic/alkaline gases and remove odors in central air conditioning systems, cleanrooms, or industrial exhaust setups to meet environmental standards.
Q:What structural styles do you offer?
We offer four main types: Pleated (most common), Parent-Child Frame, Bag/Pocket, and Flat Panel designs.
Q:How efficient is the odor removal?
Our filters use high-quality carbon-impregnated media that achieves an adsorption efficiency of ≥80%.
Q:What frame materials are available?
You can choose between Aluminum alloy profiles or Galvanized Iron frames depending on your structural needs.
Q:What are the standard thicknesses?
Common product thicknesses are 21mm and 46mm, though the internal filter media varies from 3mm to 10mm.
