MERV 13 Pleated Air Filters and Filter Media, Factory-Direct
We make our own MERV 13 media and assemble the finished filters in three production bases. Mill pricing, batch test reports on every order, FCL dispatch in as fast as 7 working days.
WHY BUYERS ARE MOVING UP TO MERV 13
The market is moving beyond basic filtration.MERV 13 creates a higher-value product tier for multiple demand scenarios.
SMOKE &FINE PARTICLES
ALLERGY &IAQ
CODE / SPEC
The math for your customers: MERV 13 blocks at least 85% of particles at 1–3 microns and 50% at 0.3–1 microns.
The math for you: one SKU tier that sells through in smoke season, allergy season, and code season.
What We Ship?
MERV 13 Filters Built Around Your Application
From finished pleated filters to filter media rolls and commercial pocket filters, we supply MERV 13 solutions for distributors, filter fabricators, HVAC suppliers, and OEM customers.Choose the product format you need. Then customize the media, frame, dimensions, and configuration around your application.
01 — MERV 13 PLEATED PANEL FILTERS
A customizable finished filter for standard and higher-efficiency HVAC applications.
Choose from cardboard, aluminum, galvanized steel, stainless steel, or skeleton frames, with aluminum depths available in 46, 69, and 90 mm.
Dimensions, media, and frame construction can be customized in inch or metric sizes, including production to your drawing.
For higher-airflow systems, a wire-backed version is available in G3–F7 grades, using a steel grid thermally laminated to the media for additional pleat support under static pressure, with a rated 400 Pa final resistance.
Deep pleating increases the available media surface area compared with flat media, helping support lower initial resistance and longer service intervals.
Best for: Distributors · HVAC suppliers · OEM/private-label programs
Custom options: Frame · Depth · Media · Size · Wire backing · Private label
02 — MERV 13 FILTER MEDIA ROLLS
MERV 13-equivalent media for converters and filter fabricators.
Available across F5–F9 grades, with the MERV 13 equivalent supplied in F7/F8 media and color-coded according to the EN779 convention.
Rolls are available up to 2.3 m wide, with custom slit widths and pre-cut pocket configurations to fit your fabrication process and help reduce material waste.
The media uses binder-free thermal bonding at 195–220°C. Grammage can be adjusted from 100–650+ g/m², with thickness configured around your target pressure drop and efficiency requirements.
The specification is controlled batch to batch for more consistent downstream production.
Best for:Filter converters · Fabricators · Filter manufacturers · OEM production
Custom options:Grade · Width · Slit size · Grammage · Thickness · Pocket configuration
03 — MERV 13 POCKET / BAG FILTERS
Extended-surface filtration for AHUs and commercial ventilation systems.
Our pocket / bag filters are available in F7 class, with 85% efficiency and an ePM1 ≈ MERV 13 equivalent, using aluminum or galvanized steel frames.
Choose from 5–8 pocket configurations according to airflow and installation requirements.
The media is scrim-reinforced to help maintain bag shape under static pressure, while the extended-surface design supports high airflow with low pressure drop.
The polyester media is washable and reusable across multiple service cycles, providing an option for applications where service life and total cost of ownership matter.
Best for:AHUs · Commercial ventilation · HVAC contractors · Facility applications
Custom options:Frame · Pocket count · Size · Media · Configuration
ONE SUPPLIER. THREE MERV 13 FORMATS.
Whether you need a finished pleated filter, media for your own production line, or commercial pocket filters, we can build the MERV 13 product around your specification.
Finished Filters · Filter Media · Pocket / Bag Filters
MERV 13 Specifications, Clearly Defined
Everything your purchasing and engineering teams need to confirm the fit — from filtration efficiency and media construction to frame options, dimensions, and available documentation.
01 — MERV 13 Pleated Filters & Wire-Backed Media
| Specification | Details |
|---|---|
| Efficiency | MERV 13 per ASHRAE 52.2; EN779 F7–F8 / ISO 16890 ePM1 equivalent |
| Media | 100% synthetic polyester, progressive-density construction |
| Media Grade | F7–F8 for MERV 13 applications |
| Color Coding | F7 pink/purple · F8 yellow, following EN779 convention |
| Bonding | Binder-free thermal bonding at 195–220°C |
| Reinforcement | Scrim standard; wire-backed steel grid option |
| Wire-Backed Media Grade | G3–F7 |
| Final Resistance | 400 Pa for wire-backed version |
| Frame Options | Cardboard, aluminum, galvanized steel, stainless steel, or skeleton frames |
| Aluminum Depths | 46 / 69 / 90 mm |
| Sizes | Standard metric and inch sizes; custom dimensions available to drawing |
| Grammage | 100–650+ g/m², adjustable |
| Operating Temperature | Up to 80°C |
| Operating Humidity | Up to 80% cardboard; 100% metal |
| Washability | Washable/reusable polyester media; retains structure across cleaning cycles |
| Customization | Media, frame, dimensions, grammage, thickness, reinforcement and configuration can be customized |
02 — MERV 13 Pocket / Bag Filters & Bag Media
| Specification | Details |
|---|---|
| Filter Class | F7 class |
| Efficiency | 85% efficiency; ePM1 ≈ MERV 13 equivalent |
| Media | Synthetic polyester |
| Media Construction | Scrim-reinforced |
| Frame Options | Aluminum or galvanized steel |
| Pocket Configuration | 5–8 pockets |
| Airflow Performance | Low pressure drop at high airflow |
| Washability | 100% washable/reusable polyester across multiple service cycles |
| Application | AHUs and commercial ventilation |
| Media Grade | F7 class / MERV 13 equivalent |
| Configuration | Custom pocket configurations available |
| Media Roll Width | Up to 2.3 m |
| Slit Widths | Custom slit widths available |
| Pre-Cut Configuration | Pre-cut pocket configurations available |
| Grammage | 100–650+ g/m², adjustable |
| Customization | Media, dimensions, grammage, thickness, roll width and configuration can be customized |
Built to Your Specification
Standard sizes are only the starting point.
Whether you need finished MERV 13 filters or filter media for your own conversion line, we can customize the specification around your application — including media grade, grammage, thickness, dimensions, reinforcement, frame, roll width and configuration.
Need to match an existing filter or media? Send us your drawing, specification sheet, or sample.
PRIVATE LABEL, SAMPLE MATCHING & THE DETAILS THAT MATTER
Need more than a standard MERV 13 filter?
Send us your existing filter, drawing, or specification. We can work from your requirements to match the product configuration, provide private-label packaging, and support the documentation your purchasing team needs.
01 — SAMPLE MATCHING
Send Us the Filter. We’ll Work From It.
Already have a filter your market accepts?
Send us a sample, drawing, specification sheet, or competitor filter. Our team can work from the existing configuration, including:
- Dimensions
- Media
- Frame
- Filtration efficiency
Most sample-based quotations are provided within one business day.
02 — PRIVATE LABEL
Your Brand. Your Packaging. Your Product.
Build your own MERV 13 product line without setting up your own production line.
We support private-label branding and packaging, including:
- Brand printing on filter/frame or media
- Custom product boxes
- Private-label packaging
- Amazon-ready retail packaging
Your specifications stay with the same production system and QC process.
03 — TESTING & DOCUMENTATION
Every Batch. Documented.
For B2B purchasing, consistent documentation matters as much as the filter itself.
We provide batch mill-test reports with orders, with third-party documentation available when required, including:
- ASHRAE 52.2
- ISO 16890
- EN779
- EN1822
Third-party reports can also be publicly shown for verification.
04 — LEAD TIMES YOU CAN PLAN AROUND
7–15 Working Days. Built Around Your Schedule.
For standard specifications, FCL dispatch can be as fast as 7 working days.
For customized specifications, typical lead times are 7–15 working days, depending on the configuration and order requirements.
Our production capacity is 30,000–40,000 units per month across three production bases.
Standard Specs → As Fast as 7 Working Days
Custom Specs → 7–15 Working Days
05 — MOQ THAT FITS THE PROJECT
From First Container to Ongoing Supply
Whether you are testing a new product line, supplying a project, or building an ongoing distribution program, MOQ can be discussed around your order requirements.
Suitable for:
Distribution · Project Orders · First Container · Ongoing Supply
Pricing can scale with order commitment and annual volume.
FACTORY ADVANTAGE
ONE MEDIA LINE. ONE POINT OF ACCOUNTABILITY.
When your filter supplier also controls the media production, specification changes, quality control, and finished-filter assembly stay within one production system.
That means fewer handoffs between suppliers — and a more direct path from specification to finished product.
| Our Integrated Production | Trading / Outsourced Supply | |
|---|---|---|
| Media | Media produced in-house and controlled within the same production system | Media may be sourced from third-party mills |
| Pricing | Factory-direct / mill-based pricing | Additional supplier or trading-company markup may apply |
| Specification Changes | Direct communication with the production team | Changes may require coordination between multiple parties |
| Quality Control | Media production and finished-filter assembly are controlled within the same system | Media production may be outside the finished-filter supplier’s direct control |
| Custom Media | Custom requirements such as grammage, width, and configuration can be discussed directly with production | Customization may depend on the upstream media supplier |
| Lead Time | 7–15 working days for standard/custom specifications; FCL dispatch as fast as 7 working days for standard specs | Lead time may include additional coordination and handling |
WHY THE SUPPLY CHAIN MATTERS
A filter is only as consistent as the supply chain behind it.
When media production → filter conversion → testing → packaging are connected within one production system, your purchasing team has a clearer point of contact when specifications change or a new requirement comes up.
From media specification to finished MERV 13 filters, you work with one production system instead of coordinating multiple suppliers.
FAQ — MERV 13 BUYING QUESTIONS, ANSWERED.
Q1：SHOULD I CHOOSE MERV 13 OR MERV 11?
A: Both can be suitable depending on the application and market.
MERV 11 can be considered for more price-sensitive applications and existing systems designed around lower filtration levels.
MERV 13 is suited to applications where customers are looking for higher filtration performance, including smoke, allergy, IAQ, or specification-driven requirements.
If you are building a product range, we can discuss the appropriate filtration level for your target market and application.
Q2 ：WILL MERV 13 RESTRICT AIRFLOW?
A: MERV 13 does not automatically mean excessive airflow resistance.
Actual pressure drop depends on the media construction, filter size, pleat configuration, airflow rate, and system design.
For older HVAC systems, compatibility should be checked before upgrading from a lower filtration level.
Q3：DO YOU SUPPLY FILTERS ABOVE MERV 13?
A: Yes.Our pleated filter media can be supplied in grades up to F9, providing higher filtration performance for applications that require it.If you have a specific efficiency target, send us your requirements and we can recommend the corresponding product configuration.
Q4：CAN YOU MATCH OUR EXISTING FILTER?
A: Yes.
Send us your existing filter, drawing, specification sheet, or competitor sample.
We can work from the existing product configuration, including:
Dimensions · Media · Frame · Filtration Efficiency
Most sample-based quotations are provided within one business day.
Q5：WHAT IS YOUR MOQ?
A: MOQ can be discussed according to the project and supply program.
We support different purchasing scenarios, including:
Distribution Orders · Project Orders · First Containers · Ongoing Supply
For ongoing programs, pricing can scale with order commitment and annual volume.
Q6： CAN YOU PROVIDE AMAZON-READY OR PRIVATE-LABEL PACKAGING?
A: Yes.We support private-label product and packaging customization, including:
- Private-label branding
- Custom product boxes
- Retail packaging
- Amazon-ready packaging
Send us your packaging requirements and branding specifications for review.
Q7：WHAT TEST REPORTS AND DOCUMENTATION DO YOU PROVIDE?
A: Batch mill-test reports are provided with orders.
Third-party documentation can also be provided when required, including:
ASHRAE 52.2 · ISO 16890 · EN779 · EN1822
Third-party reports can also be publicly shown for verification.
