Skeleton Style Activated Carbon Filter with Double Dragon Bone High-Intensity Design
For demanding industrial environments, our Skeleton Style Activated Carbon Filter provides unmatched durability and filtration surface. Featuring a unique double dragon bone (skeleton) support structure, this high-intensity air filter is built to withstand high-velocity airflow in industrial chemical industries. The increased media thickness (up to 10mm) ensures deep-bed adsorption for heavy-duty gas phase filtration and odor control.
Product Key Features
- Rugged Construction: Skeleton style frame with double-layer dragon bone for superior mechanical strength.
- Enhanced Adsorption: Utilizes 10mm thickness activated carbon media for extended service life and better chemical capture.
- Low Operating Cost: Balanced large filter area ensures high efficiency with minimal energy consumption.
- Multi-Format Selection: Available in Pocket, Panel, and Skeleton styles to meet diverse installation needs.
Material & Craftsmanship
- Structural Frame: Heavy-duty galvanized steel or aluminum alloy.
- Support System: Internal double dragon bone skeleton to prevent media deformation.
- Active Media: High-density activated carbon felt available in various thicknesses.
Applications
- Petrochemical & Chemical Industries: Ideal for filtering corrosive acid and alkali gases in oil refineries and chemical processing plants to prevent equipment corrosion and environmental leaks.
- Large-scale Manufacturing Plants: Designed for high-velocity exhaust systems in automotive painting or adhesive production to manage high concentrations of volatile organic compounds (VOCs).
- Waste Management & Odor Intensive Zones: A robust solution for managing strong, pungent smells in wastewater treatment facilities and municipal solid waste management zones.
- Industrial Gas Phase Filtration: Specifically built for heavy-duty gas phase filtration where deep-bed adsorption is required to capture toxic chemical vapors.
- Laboratory & Research Exhaust: Provides a stable and high-intensity filtration stage for laboratories handling aggressive chemical reagents and solvent vapors.
Competitive Comparison
| Feature | Our Skeleton Style Carbon Filter | Standard Heavy-Duty Filters | The Chuqi Advantage |
| Structural Integrity |
Double dragon bone support structure |
Single-layer or weak internal wire |
Unmatched Durability: Prevents media deformation under high-velocity airflow. |
| Media Thickness |
Up to 10mm thickness carbon felt |
Standard 3mm – 5mm media |
Deep-Bed Adsorption: Extends service life and increases chemical capture capacity. |
| Mechanical Strength |
High-intensity air filter design |
Lightweight industrial filters |
Reliability: Built to withstand demanding industrial chemical industries without structural failure. |
| Operating Efficiency |
Balanced large filter area |
Narrower filtration surface |
Energy Efficiency: Maintains high efficiency with minimal energy consumption and lower pressure drop. |
| Format Flexibility |
Available in Pocket, Panel, and Skeleton styles |
Limited to single format |
Versatility: Meets diverse installation needs across various factory exhaust setups. |
Specifications
| Material |
Activated Carbon |
Brand |
CHUQI |
| Condition |
New |
Origin |
Shandong, China |
| Product Name |
Activated Carbon Filter |
Application |
Air Filtration/Cleanroom |
| Efficiency |
99.995% |
Pore Size |
0.3μ |
| Dimensions |
120/220m/custom |
Thickness |
3 / 5 / 8 mm |
| Weight |
2.1 kg |
Color |
Black |
| Filter Type |
High Dust Capacity |
Function |
Air Filtration |
| Packaging |
PE bags/OEM |
OEM Service |
CHUQI |
